Concorde Wooden Floor
Concorde Wooden Floor System
Modular system made of chipboard, composed of wood core particles bound together by heat hardener resins and obtained with a continuous process of thermo-pressing so as to guarantee high homogeneity of mechanical characteristics and dimensional stability, and is widely used in Office Building, Center, Renovation, and Distribution applications.
Finishes Full range of functional & aesthetical finishes.
Bare/HPL/Vinyl Finished CSCSWP Panel + Rigid Grid System
Dimension: 600mm x 600mm or 24''(609.6mm) x 24''(609.6mm),
Perforated panel airflow rate 40%, dampers optional,
Steel pedestals provide excellent impact load performance,
Vibration proof locking nut for fast and stable installation,
Steel stringer provides excellent loading performance.
Finishes Full range of functional & aesthetical finishes.
| CSCSWP System | PSA MOB Grade | Concentrated Load (kN, 2.4mm) | Uniform Load (kN/m²) | Safety Factor | Soft body Impact (40kg, 1000mm) | Hard body Impact (4.5kg, 600mm) |
| CSCSWP800 + Rigid Grid System | Medium | 3 | 12 | 3 | pass | pass |
| CSCSWP1000 + Rigid Grid System | Heavy | 4.5 | 20 | 3 | pass | pass |
| CSCSWP1250 + Rigid Grid System | Extra Heavy | 5.5 | 30 | 3 | pass | pass |
